100 Ton Semi Trailer
Container Self-Loading Trailer has the characteristics such as high strength, strong lifting force, efficient unloading, and so on.Subjected to shot blasting process, bottom painting once, and again with Polyurethane combination painting.Polyurethane combination painting, high oxidation resistance, stronger adhesion. High oxidation resistance and stronger…
Container Self-Loading Trailer has the characteristics such as high strength, strong lifting force, efficient unloading, and so on.Subjected to shot blasting process, bottom painting once, and again with Polyurethane combination painting.Polyurethane combination painting, high oxidation resistance, stronger adhesion. High oxidation resistance and stronger adhesion.Specially designed anti tire abrasion suspension system prevents tire offset after loading. Meanwhile, it’s easy to disassemble and maintain.
|
Item |
Specification |
|
Brand |
Haoyue |
|
Application |
Coal/Mine/Stand/Stone Loading |
|
Dump Style |
Rear Dump |
|
Loading Capacity |
30T-100T |
|
Axle |
2/3/4*13/16T |
|
Length |
11000mm |
|
Width |
2500mm |
|
Height |
2800mm |
|
Cylinder |
HYVA (model is according to the length of cargo box) |
|
Floor Plate Thickness |
5mm |
|
Cargo Thickness |
4mm |
|
Cargo Style |
Rectanglular/Round |
|
Front Axle Lifting |
Available |
|
Main Beam |
Material Q345/T700 |
|
Height: 500mm |
|
|
Upper Plate: 14mm |
|
|
Middle Plate: 8mm |
|
|
Lower Plate: 16mm |
|
|
Tire |
11.00R20/12R222.5*8/12/16 pieces |
|
Rim |
8.0/9.0*8/12/16 pieces, steel/aluminum |
|
Suspension |
Mechanical/Airbag |
|
Leaf Spring |
90mm*13/16mm*10 pieces |
|
Landing Gear |
28T two-speed, JOST |
|
King Pin |
#50(2″)/#90(3.5″), JOST/Other Brand |
|
Tool Box |
Steel/aluminum |
Stable and long-using life hydraulic support system, HYVA Brand.
Polyurethane combination painting, high oxidation resistance, stronger adhesion.
Strong loading capacity of 30-100 Tons. Finite element analysis used on vehicle to ensure product performance.
Packaging & delivery
1. Bulk Packing and Bulk Transportation
2. Bulk Packing and RO-RO Transportation
3. Trailer Whole Body Waxing
Port
Qingdao Port of China/Tianjin Port of China
FAQ
1. Can you satisfy special requirement?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
2. How can you guarantee quality?
Our raw material and OEM parts including axle,suspension,tyre,are purchased centralized by Tongxiang company.every node will be inspected strictly.Moreover,advanced equipment rather than only worker is been applied duringthe whole producing process to ensure the welding quality.
3. What’s the delivery time?
The delivery time is within 25working days after receiving your advance payment.
4. Can i have samples of this type of flatbed semi trailer to test the quantity?
Yes,you can buy any samples to test the quality ,our MOQ is 1 set.
5. What is the MOQ?
One set trailer or truck.we suggest two trailers or trucks one time to save the freight.
Specification
| Brand | Haoyue |
| Application | Coal/Mine/Stand/Stone Loading |
| Dump Style | Rear Dump |
| Loading Capacity | 30T-100T |
| Axle | 2/3/4*13/16T Haoyue/FUWA/BPW |
| Length | 11000mm |
| Width | 2500mm |
| Height | 2800mm |
| Cylinder | HYVA (model is according to the length of cargo box) |
| Floor Plate Thickness | 5mm |
| Cargo Thickness | 4mm |
| Cargo Style | Rectanglular/Round |
| Front Axle Lifting | Available |
| Main Beam | Material Q345/T700 |
| Tire | 11.00R20/12R222.5*8/12/16 pieces Linglong/Triangle/Double-Coin/Bridgestone |
| Rim | 8.0/9.0*8/12/16 pieces, steel/aluminum |
| Suspension | Mechanical/Airbag |
| Leaf Spring | 90mm*13/16mm*10 pieces |
| Landing Gear | 28T two-speed, JOST |
| King Pin | #50(2")/#90(3.5"), JOST/Other Brand |
| Tool Box | Steel/aluminum |
| Height | 500mm |
| Upper Plate | 14mm |
| Middle Plate | 8mm |
| Lower Plate | 16mm |
Request a Quotation
Send us your destination port and any special requirements. Our team reviews the configuration and prepares a quotation.
